KS Digital Line-Master
29.999,00 €*
Verfügbarkeit: Bitte kontaktieren Sie uns in dringenden Fällen.
The only linear phase mastering monitor utilizing cylindrical wave technology, worldwide.
Developed and designed for use in the most demanding of mastering studios, the LineMaster is an uncompromising Loudspeaker system. The highest possible sound neutrality utilizing the linear phase and value FIRTEC ™ filter. The dynamic membrane control (DMC ™) permits a lively impulsive base, a linear phase and no buildup or decay oscillations of the membrane. Also the controlled sound emission of the near field extension technology in NEXT ™ permits highest control, especially in the mastering area. The oversized power reserves of the
output stage with 400W / 200W / 200W ensure that the conversion of the electrical signal occurs with the lowest possible level of distortion. Especially when mastering, one needs the assurance that the reproduction of the music is exact and unadorned, with the complete frequency range from the highest of highs to being able to perceive the deepest rumble of the airconditioning in a symphony orchestra.
Technical Specifications:
| AD / DA converter | 24 bit sigma delta, 64x oversampling |
| digital IN, OUT: | AES3 format , 32 – 56(110)KHz |
| 192 KHz vorbereitet | |
| analog IN, OUT: | XLR-symmetric, activ bypass output |
| DSP: | 60 MHz 32 bit floatingpoint, 1500 dB dynamic |
| process: | FIRTEC equalization |
| 2 difference FIR-crossover | |
| speaker timealignment, limiter, 2 FIR-presets, 3 userprogrammable peakfilter with frequence, gain and peakcontrol lowshelving,heighshelving, distance shift, phase reverse, digital mono | |
| room equalization: | FIRTEC system - equilasation for control room |
| chassis: | 1'’ radiator on NE-X-T adapter, four 6.5" midrange carboncone, two 8" DMC carboncone driver |
| amplifier: | 350W / 200W / 100W MOSEFET technology |
| SPL: | 125dB peak |
| Remote Control: | all parameter free controlable hardware or software remote control available |
| dimensions: | 170 X 30 X 33 cm 19.7 kg |
| frequency range: | 20 - 24000 Hz (+/-3dB) |
For more information, please visit this products webpage.
