ATC SCM150ASL Pro

Entdecken Sie den ATC SCM150ASL Pro: 3-Wege-Aktivlautsprecher mit präzisem Klang, 350W Tri-Verstärker und 6 Jahre Garantie für Ihr ultimatives Hörerlebnis.

23.299,00 €*

Verfügbarkeit: Bitte kontaktieren Sie uns in dringenden Fällen.

Hersteller: ATC
Produktinformationen "ATC SCM150ASL Pro"

SCM150ASL Pro: 3-way Active

Features

25mm soft dome tweeter.
Full "SL" spec 15"/375mm bass driver.
ATC 75mm "Super Dome" mid driver.
On board ATC grounded plane 350W Tri-amplifier.
LF contour control.
Clip indication.
6 year warranty.

Specifications

Drivers :
HF 25mm, Mid 75mm, LF 375mm
Amplitude Linearity (±2dB) :
60Hz-17kHz
Cut-off Frequencies (-6dB, free-standing) :
25Hz, 22kHz
Horizontal Dispersion :
±80°, Coherent
Vertical Dispersion :
±10°, Coherent
Max. Continuous SPL (1 metre) :
117dB
Crossover Frequencies :
380Hz, 3.5kHz
Input Connectors :
Male XLR
Input Sensitivity :
1V
Input Sensitivity Trim :
±6dB
Input Impedance :
Balanced > 10kΩ
Amplifier Output :
Bass 200W, Mid 100W, High 50W
Filters :
Even Order Critically Damped
Overload Protection :
Active FET momentary gain reduction plus thermal tweeter protection
Front Panel Indicators :
Power On indicator, Gain Reduction warning
LF EQ :
+6dB @ 40Hz
Dimensions (HxWxD) :
884 x 498 x 568mm (34.8" x 19.6" x 25.5") Depth with amplifier at rear adds 3"
Weight :
75kg / 165lbs
